Zoom Power

A friend asked me the other day:

Mike – I don’t understand how to compare the zoom power of my Nikon P100 26x zoom to the Canon 28-300mm zoom with my Canon 5d MkII.

Good question. But I think it is the wrong question. Or at least, the way the question is asked shows me that it might be based on the wrong premise.

The term “zoom power” seems to indicate that the ability to chance focal length settings through a wide range is a good thing. Like, a 10-500mm lens would be a good thing. Some even call this “ultra zoom technology” – you know, as in: just add the word “technology” to a term and it somehow gains in value. But only to the ignorant: when someone says “technology” like that, I just hear “marketing”.

Here’s why I think a wide zoom range (i.e. a wide ability to change from one focal length to another) is not necessarily a great thing.

First, it is a compromise. The wider the adjustment range, the more this lens will be a compromise at all lengths. A wide zoom range lens will neither be a great wide, nor a great standard, nor a great telephoto lens. Its aperture will be small, and it will vary. It will show pincushion and barrel distortion at both ends. It will not be sharp. The more a lens is like a prime lens, on the other hand, the clearer, faster, and sharper it will be.

The other reason is that of discipline. With a lens that can go from very wide to very long. you will never have a reason to be consistent in your images. Your pictures will not take on any particular look and feel: rather, each image will be different. Neither fish nor fowl, you might say.

The reason we have these super zoom compacts is for convenience, of course. But a lot of the time, this is wishful thinking kind of convenience. I hear it often: “yes, but I don’t want to own multiple lenses to get from 10mm to 500mm”. Sure, like I don’t want to die or pay taxes. Both are, alas, inevitable.

So only you can decide whether you want a wide range zoom camera or lens. To me, the wider the zoom range, the more everything will be a compromise, and the worse my pictures will be. But you may have different thoughts if size and convenience are more important to you than quality.

My lenses are a 16-35 (“2.2x zoom”), the 100mm, 50mm and 35mm primes (“0x zoom”), a 70-200 (“2.9x zoom”), and a 24-70 (“2.9x zoom”), and they are among the best on the planet. In fact my entire range of lenses from 16 to 200mm is equivalent to one 12.5x zoom, in those terms. This shows you how little those terms really mean.

But since you ask: a 28-300 mm zoom would be a “10.7x zoom” in marketing-speak. So the compact 26x zoom has a much wider range. 2.43 times wider, in fact!

Me tonight

Taken how?

  • 16-35mm lens on a 1.3 crop camera, set to 16mm, meaning, effective 21mm length.
  • Manual mode, 1/30th, f/2.8.
  • 400 ISO,

And then you get as close as you can to the closest object. The closer, the blurrier the distant objects (me!) will become.

Another blog post in a few minutes, with a reader question.

Simple Means.

Today, I taught a flash workshop that concentrated on the use of just small flashes. (Of course as you know I am doing an in-depth version of that workshop on March 19, with special Guest Star David Honl, yes? See www.cameratraining.ca/Flash-Honl.html – not to be missed!)

Anyway, simple portrait lighting with speedlites. You normally use wireless TTL for that – multiple flashes that the camera talks to using its wireless TTL technology. All major brands support this.

So here we have a simple shot of one of tonight’s students, using:

  1. a 580EX flash on our right…
  2. …shot through an umbrella, and
  3. a 430EX flash on our left…
  4. …using a Honl 1/4″ grid and a blue gel.

All this fired from a 580EX on a Canon Camera (if you have a Canon 7D or a 60D, or a Nikon, you can use your popup flash for this).

If you set the two flashes to different “groups”, i.e. A and B, you can set the ratio to what you like (e.g. A:B set to 4:1 means A is 4 times, or two stops, brighter than B). On Nikon, the system is the same although the way you set it is different (stops with respect to zero).

One important thing to remember: a key difference between strobes (you meter by measuring incident light, and it’s always good whatever the subject) and speedlites (TTL meters reflected light). So when using TTL instead of a studio, your subject makes a difference.

A subject with dark hair, a dark top, and against a dark background, will be overexposed so you need to use Flash Compensation of minus 1 to minus 2 stops. In the shot above, I used minus 1.3 stops.

Go try this if you haven’t. It’s fun. As a minimum, you need a camera with an on-camera flash (or use the pop-up on a 7D or 60D or a Nikon); one additional flash; a light stand; an umbrella; a bracket to mount them together; and a reflector (see yesterday’s post).

Reflect on this

I taught a very enjoyable class on “Portrait Photography” last night. I taught six students about studio lighting. Strobes, modifiers, light meters, backdrops, that sort of thing.

And one message was: it can be simple. One student wrote me just now:

I just wanted to tell you that I really enjoyed tonight’s workshop, which was excellent.  I learnt so much about studio lighting in just 3 hours.  I had always wondered how the big lights work prior to tonight’s workshop, and I have to say that you solved the mystery for me tonight.

Yes it can be simple. Like in this shot, made with just one light (a Bowens 500 Ws strobe fired using pocketwizards, through an umbrella):

Michael Willems, by Franklin Wang

Michael Willems, by Franklin Wang

Observant readers (no no, not religiously observant – I mean readers who look carefully) will see that I am at 1/160s on the meter, and am using 200 ISO.

(Why 200 ISO? Should I, in a studio setting, not be using 100? Not when some students use Nikon cameras, which cannot easily go down below 100 ISO. That’s why. And why 1/160th? Because being slightly below your maximum flash sync speed, so ambient light does nothing while you avoid cutting off a bit of the image, is sensible in a studio. That’s why.)

So your settings in a studio might be:

  • Camera on manual;
  • 1/200th second at f/8;
  • 100 ISO;
  • Now set the lights to those values, using a flash meter.

I used a black background, away from the lights. That way it remains black.

So if you think that is a bit contrasty – we add a second light, right? And power it 1-2 stops below the first (2:1 or 4:1 ratio)?

Maybe.

Or maybe we just use a reflector. Saves the planet.

Michael Willems, by Franklin Wang

Michael Willems, by Franklin Wang

That way we save the second light which we can then use for the background, or for hair light, or for other funky effects.

The final picture is by another of the students:

Michael Willems, by Richard Smart

Michael Willems, by Richard Smart

Hey! Now that black background is light grey!

That is the point too. Black can be black (it is black when it has little light falling on it) or bright white (it turns white when it has lots of light falling on it). That is why I like black. White is much harder to control – it is easy to make it white, but tough to get it darker than mid grey in a typical studio.

As for the last picture: of course the top needs to be cropped off, but that is the point: these images are straight from the students’ cameras.

Oh – and the purple edge light is a simple 430EX speedlite, with a Honl grid and a Honl gel. Also fired using a Pocketwizard.

And yes, I think I can carry it off, purple.

Can you tell my spouse?

A student recently asked me to explain to his or her spouse (anonymity will be preserved) why it is worth investing in lenses.

Michael in The Plaid Chair (Photo: Peter McKinnon)

Michael in The Plaid Chair

And indeed I am happy to do this. Not because I have any stake in selling lenses (I teach, at various venues including Henry’s School of Imaging, but I have no stake in selling anything anywhere). But because:

  1. I strongly believe the lens is the most important part of photographic equipment between you and a great picture.
  2. A lens keeps its value much better than a camera does.

Let me explain.

  • The lens determines how sharp your picture is. Good lenses are simply sharper, and with today’s sensors this difference is noticeable.
  • The lens determines how fast your shutter speed is. And hence, how blurry the image. A faster lens (“fast” means “how wide is the aperture”, i.e. “how low is the minimum F-number this lens can go to”) means more light can get in – which means faster shutter speeds are possible at the same ISO.
  • The lens determines how blurry you can make the background. An f/2.8 lens gives you, if you want it, a much blurrier background than a consumer-grade f/3.5-5.6 lens. A “prime” (fixed) f/1.4 lens, even more so.
  • Good lenses focus faster, are quieter, have better “bokeh” (look better where they are out of focus), are water- and dust-sealed, and so on.

Those are very important factors whose importance it is almost impossible to overstate. Photojournalists like me use f/2.8 zoom lenses and f/1.4 primes. for a reason. For several reasons.

And finally- a lens keeps its value. A camera – not so much (next year it is worth half; a afew years later it has $0 value). A good lens keeps its value for decades.This is because 20 years from now it will still do what it does today (let through photons), and because the intrinsic value of the optical glass is a larger part of the value of the lens.

This is why lenses are worth buying. They make much more difference to images than the camera does, and they are a much safer investment.

One Day Special: Advanced Flash

Good news. The One-Day Only Special “Michael Willems’s Advanced Flash”, with special Guest Star David Honl (yes, the David Honl, the inventor and creator of that great range of small flash modifiers!), is now open for booking.

  • When? March 19. From 11AM until 2:30PM
  • Where? Downtown Toronto, Henry’s School of Imaging flagship location at Church and Queen Streets.
  • What? Check the syllabus at www.cameratraining.ca/Flash-Honl.html
  • How Much? $175

Registration is limited, so go to the Henry’s School of Imaging site today to reserve your space – click here:

www.schoolofimaging.ca/Courses/64044-Advanced-Flash.aspx

Registration is open now and space is limited, so I recommend you book soon if you are interested. In this four-hour workshop in downtown Toronto, you’ll learn a lot about advanced use of flash, and Dave will show you some signature shots made with simple, small flashes that you can also afford.

Not to be missed if you would like to be exert at using small flashes to create professional shots, even when the light is tough.

About that home studio

One more about the simple TTL home studio. I can give you some pointers to do your own.

Here’s how.

You need:

  1. A modern SLR camera.
  2. A lens – anything over 50mm will do. A 50mm f/1.8 might be a great choice: sharp and affordable (and if you need it, fast).
  3. If you have a Nikon, or a Canon 60D or 7D, just one flash (a 430EX/580EX for Canon or an SB600/SB900 for Nikon).
  4. If you have a different Canon camera, an additional 580EX to command the other flash.
  5. An umbrella (shoot through).
  6. A stand for the flash, with a mount for flash plus umbrella.
  7. A reflector (silver or gold or white, or a multi-purpose one).
  8. A stand for that reflector.

As an option, another flash with a small stand to light up backgrounds, but this is not a must have. You can just move the umbrella and subject closer to the wall if you want the wall to be lighter.

Now that you have the equipment:

  1. Set your flash to “slave” (Canon) or “remote” (Nikon) mode. Use the manual to find out how. On a modern Canon with a modern flash you can use the camera to set the flash.
  2. Set up your on-camera flash to be the “master” (“Commander”, on Nikon).
  3. Ensure that the on-camera flash is not going to fire (it will only  send commands to the remote flash, but it will not actually fire – else you get a shadow).
  4. Move the umbrella close to your subject. For a “standard” portrait, the best position is 45 degrees up, off to the side 45 degrees.
  5. Move the reflector close on the opposite side.
  6. Set your camera to manual exposure mode, f/8, 1/125th second, 100 ISO (or 200 on a Nikon).
  7. Take a test shot.
  8. Check the histogram. If you are shooting a dark subject against a dark wall, you may need negative (perhaps -1 stop) Flash Exposure Compensation; if you are shooting a light subject against a white wall, you may need positive (perhaps +1 stop) Flash Exposure Compensation.
  9. Make sure there is a catch light in the subject’s eyes. Ensure that any glasses do not reflect (move subject or umbrella if they do).

It is as simple as that. You will have studio quality shots, for very little investment. Shots like this (which I made with the exact setup above):

With a modern camera and flash and a little knowledge, it really can be that easy.

Granigif

That cryptic title means “Animated GIF at the Granite Club”. Which is where I was teaching portrait photography last night.

I cannot image a more fun way to spend an evening: some of the most committed, fun, outspoken, and friendly people I have had the pleasure of teaching.

So let’s start with how I set up. Click below to see it as an animated GIF. The time elapsed here was over an hour:

Studio Photography Lesson Setup, by Michael Willems

Studio Photography Lesson Setup, by Michael Willems

Last night was a lightning-fast lesson in portrait photography basics, from lights to pocketwizards to positioning techniques.

The interesting thing, I think, is that while for full control, the more “stuff” you have the better, you can often keep it remarkably simple.

A shot with “the standard four lights” might be this:

Portrait at The Granite (Photo Michael Willems)

Portrait at The Granite

That uses a key light (softbox), a fill light (umbrella), a hair light (Honl snoot), and a background light (Honl Grid).

But you can also keep it simpler. For a lady with light hair, I would not light up the background. We would also not really need the hair light. So now indeed it is simpler:

Robbin at The Granite (Photo: Michael Willems)

Robbin at The Granite

Beautiful, no?

But the real surprise is the simple setup on the left: you can just see it. A TTL flash through an umbrella. A reflector to provide fill light. And a background light to add a bit of brightness to the available background. Now all we are using, then, is two flashes and some affordable stands and a reflector.

That gives us:

Matt at The Granite (Photo: Michael Willems)

Matt at The Granite

You see: you can often keep a studio setup simple. Why use a light when a reflector will do just as well?

Studio photography is incredibly rewarding. If you think so too, I strongly recommend you take a course or private coaching and learn how to do it.

Another…

…delayed post. Things in my life are intervening, but here is a snap: a food shot. Inspired by the feeling that at 2am, I am hungry.

How do you shoot that?

  1. A soft light above the food (a flash in an umbrella).
  2. A back light from behind the food, to give it that extra sparkle (and to light up the steam).
  3. A simple composition.

Simple once you know, as always.

Another light example

Here is another lighting example for you.

A very nice lady with an amazing traditional dress (which I am told took a year to make, which does not surprise me):

Croatian dress and mystery pot (Photo: Michael Willems)

Croatian dress and mystery pot

So how was that lit?

Here’s how.

  • First, I exposed properly for ambient light. That is why the background foliage looks good.
  • The camera, of course, is on manual.
  • Then, I added a main light on my right – a strobe in a softbox. This again gives us nice soft light. Fired by pocketwizards.
  • Then finally, I felt it needed more. So I used a speedlight in the sink, on manual, fired also by pocketwizards.

That’s how. Try some of the same if you have time!
